Rack mounting – Rockwell Automation 6186-Mxxx Industrial Monitors Installation Instructions User Manual
Page 12

12 Industrial Monitors
Publication 6186M-IN001L-EN-P - July 2008
6. Tighten the clips gradually, one at a time, in the specified sequence,
beginning with the center clips and continuing to the corner clips.
Repeat this process at least three times until the clips are hand-tight and the
gasket is compressed uniformly against the panel.
7. Tighten the mounting clips to a torque of 1.1 Nm (10 lb•in) by following the
torque sequence in step 6, making sure not to overtighten.
Rack Mounting
You can install the 1200M, 1500M, 1700M monitors directly into a rack by using the
appropriate rack adapters.
ATTENTION
Tighten the mounting clips to the specified torque to provide a proper seal
and prevent damage to the product. Rockwell Automation assumes no
responsibility for water or chemical damage to the product or other
equipment within the enclosure because of improper installation.
Cat. No.
Description
6189V-MRA12
Rack adapter for 1200M monitor
6189V-MRA15
Rack adapter for 1500M monitor
6189V-MRA17
Rack adapter for 1700M monitor
Torque Sequence
8
1
5
7
2
6
4
3
7
1
5
6
2
8
9
3
4
10
14
1
5
13
4
6
11
10
2
9
12
7
3
8
1200M Monitor
1500M and 1700M Monitors
1900M Monitor
Torque Sequence
Torque Sequence
