Publication 2364-5.11 - April 1998

R

EPLACEMENT

K

IT

I

NSTRUCTIONS

Bulletin 2364 AC Line and Control Power
Fuse Replacement

Contents

This publication contains procedures for replacing the AC line and
control power fuses. A, B, C, D, J, K, L, M, and N-code 2364 units
have single AC line fuses and E, F, and G-code 2364 units have
parallel AC line fuses.

Note: Parallel fuses should always be changed in pairs.

What This Kit Contains

Using the table below, verify that you have received the appropriate
items in your kit:

Other Items Needed

Before you begin, be sure you also have the following:

Whatever tool(s) you will need to:

Remove, loosen, and tighten bolts

Documentation:

Your drive system schematics

Your product’s user/installation manual

For this part:

You should receive this quantity:

AC line fuse

6 (A through D and J through N-code
2364 units)
12 (E, F, and G-code 2364 units)

Control power fuse (F7)

2

Control power fuse (F5) if N-code unit

2
