Page 2

Legend Strip Kit
2
Installing the Legend Strip
To reverse or change a legend strip:
1. Carefully pull the legend strip from the slot(s) on the bezel.
Slot for Legend Strip
2. If you are using the blank legend strips, mark the legends on the
matt surfaces provided for marking.
3. Re-insert the tab into the slot. Here are some helpful hints:
•
Grip the legend strip near the point where the strip enters the
slot and use short “pushes”. This helps prevent buckling of
the legend strip.
•
It may be helpful to “cup” the legend strip slightly as you hold
it. This will stiffen the legend strip and also prevent buckling.
Rockwell Automation helps its customers receive a superior return on their investment by bringing
together leading brands in industrial automation, creating a broad spectrum of easy-to-integrate
products. These are supported by local technical resources available worldwide, a global network
of system solutions providers, and the advanced technology resources of Rockwell.
Worldwide representation.
41061-044-01(A)
Copyright 1997 Allen-Bradley Company, Inc. Printed in USA
