8720SM High Performance AC Induction Motors
19
8720SM-005S1, -007S1, and -011S1 Dimensions (Before March 01)
The following motor dimensions are for 8720SM-005S1BASx thru
-011S1DCSx motors, 180 mm flange and 215 mm bolt circle
manufactured before March, 2001.
Figure 5
8720SM-005S1BASx thru -011S1DCSx Motor Dimensions
Blower
Terminal Box
3-3/16" Dia
1-5/8" Dp
N
D
E
I2
T
LA
x1
a
e
C
L
MS
Connector
Terminal Box
XI
P
M
g1
AC
S
H
HD
HA
K
AA
A
AB
F
GA
Motor
8720SM-
AB
mm
(in.)
H
1
mm
(in.)
A
mm
(in.)
HA
mm
(in.)
K
mm
(in.)
AA
mm
(in.)
AC
mm
(in.)
C
mm
(in.)
P
mm
(in.)
N
mm
(in.)
LA
mm
(in.)
M
mm
(in.)
T
mm
(in.)
005
233
(9.17)
112
(4.40)
190
(7.48)
9
(0.35)
12
(0.47)
83.5
(3.28)
240
(9.44)
106
(4.17)
250
(9.84)
180
(7.08)
13
(0.51)
215
(8.46)
4
(0.15)
007
233
(9.17)
112
(4.40)
190
(7.48)
9
(0.35)
12
(0.47)
83.5
(3.28)
240
(9.44)
106
(4.17)
250
(9.84)
180
(7.08)
13
(0.51)
215
(8.46)
4
(0.15)
011
233
(9.17)
112
(4.40)
190
(7.48)
9
(0.35)
12
(0.47)
83.5
(3.28)
240
(9.44)
106
(4.17)
250
(9.84)
180
(7.08)
13
(0.51)
215
(8.46)
4
(0.15)
Motor
8720SM-
S
mm
(in.)
XI
4
mm
(in.)
L
mm
(in.)
e
mm
(in.)
x1
mm
(in.)
a
mm
(in.)
D
2
mm
(in.)
E
mm
(in.)
I2
mm
(in.)
GA
3
mm
(in.)
F
mm
(in.)
g1
mm
(in.)
HD
mm
(in.)
005
14
(0.55)
38
(1.49)
642
(25.27)
269
(10.59)
134
(5.27)
203
(7.99)
38
(1.49)
80
(3.14)
80
(3.14)
41
(1.61)
10
(0.39)
242
(9.52)
305
(120)
007
14
(0.55)
38
(1.49)
687
(27.04)
313
(12.32)
178
(7.00)
248
(9.36)
38
(1.49)
80
(3.14)
80
(3.14)
41
(1.61)
10
(0.39)
242
(9.52)
305
(120)
011
14
(0.55)
38
(1.49)
725
(28.54)
352
(13.85)
216
(8.50)
286
(11.25)
38
(1.49)
80
(3.14)
80
(3.14)
41
(1.61)
10
(0.39)
242
(9.52)
305
(120)
