ArmorBlock MaXum 8 Input Module with 8 Connectors, Series B 7
Publication 1792D-IN051A-EN-P - February 2001
DeviceNet Cables
DeviceNet cables are described in the installation publications for the
cable base assembly of your choice. Refer to the following
publications:
•
1792D-IN009B-EN-P ArmorBlock MaXum Cable Base
Installation Guide
•
DN-6.7.2 DeviceNet Cable Planning and Installation Manual
Communicate With Your ArmorBlock MaXum I/O
Module
This ArmorBlock module’s I/O is exchanged with the master through
a poll, change-of-state, or cyclic connection.
The module consumes and produces I/O data as follows:
Cyclic - allows configuration of the block as an I/O client. The block
will produce its I/O cyclically at the rate configured.
Polled - a master initiates communication by sending its polled I/O
message to the module. The 8 input module cans the inputs and fault
bits producing a response that reflects their status.
Change-of-State - productions occur when an input changes or a
fault condition occurs. If no input or fault condition change occurs
within the expected packet rate, a heartbeat production occurs. This
heartbeat production tells the scanner module that the module is alive
and ready to communicate.
Refer to the table below for the word/bit definitions.
Type of I/O Connections Consumes Produces
Cyclic 0 Byte 3 Bytes
Polled 0 Byte 3 Bytes
Change-of-State 0 Byte 3 Bytes
Bit 07 06 05 04 03 02 01 00
Produced 0 I7 I6 I5 I4 I3 I2 I1 I0
Produced 1 ISC-H ISC-G ISC-F ISC-E ISC-D ISC-C ISC-D ISC-A
Produced 2 OW-H OW-G OW-F OW-E OW-D OW-C OW-B OW-A
Where: I = Input; ISC=Input Short Circuit in Sensor Source Voltage; OW= Off Wire
