ControlLogix Programmer Cable

2

Publication 1756-5.46 – May 1997

Install the Cable

1. Connect the right-angle connector end of the cable to your

controller at the communications port.

Communications

Port

2. Connect the straight connector end of the cable to your DTE device.
