14

Publication 1790-IN005B-EN-P - April 2003

Digital Expansion Block Specifications

The following table contains specifications that are common to
all of the expansion blocks in this document. Individual
expansion block specifications are detailed after this table.

Environmental Specifications

Operating Temperature

0 to 55°C (32 to 131°F) - Analog I/O
IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock)

Storage Temperature

-40 to 85°C (-40 to 185°F)
IEC 60068-2-1 (Test Ab, Un-packaged Non-operating Cold),
IEC 60068-2-2 (Test Bb, Un-packaged Non-operating Dry

Heat),

IEC 60068-2-14 (Test Na, Un-packaged Non-operating Thermal

Shock)

Relative Humidity

5-90% non-condensing
IEC 60068-2-30 (Test Db, Un-packaged Non-operating)

Operating Altitude

2000m

Vibration

2g @ 10-500Hz
IEC60068-2-6 (Test Fc, Operating)

Shock
Operating
Non-operating

10g
30g
EC60068-2-27 (Test Ea, Unpackaged Shock)

Emissions

Group 1, Class A
CISPR 11

ESD Immunity

8kV air discharges
IEC 61000-4-2

Radiated RF Immunity

10V/m with 1kHz sine-wave 80%AM from 80MHz to 1000MHz
10V/m with 200Hz 50% Pulse 100%AM @ 900Mhz
IEC 61000-4-3

EFT/B Immunity

1kV @ 5kHz on power ports
+2kV @ 5kHz on signal ports
IEC 61000-4-4

Surge Transient Immunity

+1kV line-line(DM) and +2kV line-eath(CM) on power ports
+1kV line-line(DM) and +2kV line-eath(CM) on signal ports
EC 61000-4-5

Conducted RF Immunity

10Vrms with 1kHz sine-wave 80%AM from 150kHzto 80MHz
IEC 61000-4-6

Enclosure Type Rating

None (open style)

Mounting

DIN rail or screw

Dimensions

52x104x42mm (2.03x4.07x1.64in)

Weight

0.3lb (0.1kg)
