14 ProcessLogix Battery Extension Module
Publication 1757-IN093B-EN-P - April 2004
Specifications
Specification Description
Electrical backplane current 5.1 V dc @ 112 mA
24 V dc @ 36 mA
power dissipation 1.424 watts
thermal dissipation 9.6 watts
sourcing capacity 200mAh
Physical module size ICP std. 1 slot wide
chassis location
(recommended default) recommended default:
slot 6 in 7 or 13-slot
slot 4 in 10 or 17 slot
weight 0.35 kg
mounting 35 mm DIN rail
Enclosure Type Rating None (open-style)
Alarm Relay
Contact voltage/current ratings 30 v dc maximum
/ 100 milliamps maximum
Channels one
ground isolation 30 V
Environmental Enclosure Type Rating None (open-style)
Operating
Temperature 0 to 60°C (32 to 140°F)
IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock)
Storage
Temperature –40 to 85°C (–40 to 185°F)
IEC 60068-2-1 (Test Ab, Un-packaged Non-operating Cold),
IEC 60068-2-2 (Test Bb, Un-packaged Non-operating Dry Heat),
IEC 60068-2-14 (Test Na, Un-packaged Non-operating Thermal Shock)
Relative Humidity 5 to 95% non-condensing
IEC 60068-2-30 (Test Db, Un-packaged Non-operating Damp Heat)
Vibration IEC60068-2-6 (Test Fc, Operating): 2g @ 10-500Hz
Shock IEC60068-2-27 (Test Ea, Unpackaged shock):
Operating 30g
Non-operating 50g
Emissions CISPR 11: Group 1, Class A
ESD Immunity IEC 61000-4-2:
4kV contact discharges
8kV air discharges
Radiated RF
Immunity IEC 61000-4-3:
10V/m with 1kHz sine-wave 80%AM from 30MHz to 1000MHz
10V/m with 200Hz 50% Pulse 100%AM at 900Mhz
EFT/B Immunity IEC 61000-4-4: ±2kV at 5kHz on signal ports
