Solid-State Output Module 11
Publication 1762-IN007B-EN-P- June 2013
Specifications
General Specifications
Specification Value
Dimensions, HxWxD 90 x 40.4 x 87 mm (height including mounting tabs is 110 mm)
3.54 x 1.59 x 3.43 in. (height including mounting tabs is 4.33 in.)
Approximate Shipping Weight
(with carton)
215 g (0.48 lbs.)
Temperature, nonoperating -40…85 °C (-40…185 °F)
Temperature, operating 0…55°C (+32…131°F)
Humidity, operating 5…95% non-condensing
Altitude, operating 2000 m (6561 ft)
Vibration Refer to the MicroLogix 1200 Controllers Installation Instructions,
publication
1762-IN006 .
Shock
Hazardous Environment Class Class I, Division 2, Hazardous Location, Groups A, B, C, D
ISA/ANSI 12.12.01
(C-UL under CSA C22.2 No. 213)
Noise Immunity NEMA standard ICS 2-230
Radiated and Conducted Emissions EN50081-2 Class A
ESD Immunity (IEC1000-4-2) 4 kV contact, 8 kV air, 4 kV indirect
Radiated Immunity (IEC1000-4-3) 10 V/m, 80…1000 MHz, 80% amplitude modulation, 900 MHz
keyed carrier
Fast Transient Burst (IEC1000-4-4) 2 kV, 5 kHz
Surge Immunity (IEC1000-4-5) 2 kV common mode, 1 kV differential mode
Conducted Immunity (IEC1000-4-6) 10V, 0.15 …80 MHz (1)
(1) Conducted Immunity frequency range may be 150 kHz…30 MHz if the Radiated Immunity frequency range is
30 MHz…1000 MHz.
