PCI Bus Card for 1746 Local I/O
7
Publication 1747-5.31–April 1998
Installing the Scanner
To install the scanner inside the computer:
1. Turn off power to the computer.
Important: If you disconnect the ac power from the computer, you lose
the chassis ground. Electrostatic damage (ESD) protection
is lost.
2. Loosen the expansion slot screw and remove the outside retaining
bracket.
3. Insert the scanner into the edge connector and tighten the expansion
slot screw on the scanner outside retaining bracket.
4. Restore power to the computer.
5. Run PCI diagnostics from the Utility disk to obtain the memory and
interrupt assigned to the scanner by BIOS at power up. Place the
software disk in the PC.
6. Type:
a:\PCISID.EXE.
7. Hit
Selecting the Cable for Your Connections
The scanner must be connected to the adapter. Use one of the following
cables to make the connection:
•
3m interconnect cable (Cat. No. 1747-PCIC)
•
10m interconnect cable (Cat. No. 1747-PCIC2)
