16 ArmorPOINT I/O 5V DC Encoder/Counter Module, Series A
General Specifications (continued)
Vibration
IEC60068-2-6 (Test Fc, Operating):
5g @ 10...500Hz
ESD Immunity
IEC 61000-4-2:
6kV contact discharge
8kV air discharge
Radiated RF Immunity
IEC 61000-4-3:
10V/m with 1kHz sine-wave 80% AM from 80...2700 MHz
10V/m with 200Hz 50% Pulse 100% AM from 900...1890 Mhz
EFT/B Immunity
IEC 61000-4-4:
±2 kV @ 5.0 kHz on signal ports
Surge Transient Immunity
IEC 61000-4-5:
±1 kV line-line (DM) and ±2 kV line-earth (CM) on signal ports
Conducted RF Immunity
IEC 61000-4-6:
10V rms with 1 kHz sine-wave 80% AM from 150 kHz...80MHz
Emissions
CSPR 11:
Group 1, Class A
Enclosure Type Rating
Meets IP65/66/67 (when marked)
Mounting Base Screw Torque
#8 screw:
0.847 Nm – Aluminum
1.807 Nm – Steel
Weight (approx.)
0.289 kg
(0.637 lb.)
Wiring Category
1
2 - on signal ports
Certifications:
(when product is marked)
c-UL-us UL Listed Industrial Control Equipment, certified for US and Canada
CE
3
European Union 2004/108/EC EMC Directive, compliant with:
EN 61000-6-2; Industrial Immunity
EN 61000-6-4; Industrial Emissions
EN 61131-2; Programmable Controllers (Clause 8, Zone A & B)
EN 61326-1; Meas./Control/Lab., Industrial Requirements
C-Tick
3
Australian Radiocommunications Act, compliant with:
AS/NZS CISPR 11; Industrial Emissions
1. Use this Conductor Category information for planning conductor routing. Refer to Industrial Automation Wiring and Grounding
Guidelines, publication
, for additional installation requirements.
2. See the Product Certification link at
for Declarations of Conformity,
Certificates, and other certification details.
