1734 POINT I/O Protected Output Module 7
Publication 1734-IN056H-EN-P - May 2013
Install the Mounting Base
To install the mounting base on the DIN rail, proceed as follows:
1. Position the mounting base vertically above the installed units (adapter, power
supply or existing module).
2. Slide the mounting base down allowing the interlocking side pieces to engage the
adjacent module or adapter.
3. Press firmly to seat the mounting base on the DIN rail. The mounting base snaps
into place.
4. To remove the mounting base from the DIN rail, remove the module, and use a
small-bladed screwdriver to rotate the base locking screw to a vertical position.
This releases the locking mechanism. Then lift straight up to remove.
ATTENTION: This product is grounded through the DIN rail to chassis ground.
Use zinc plated yellow-chromate steel DIN rail to assure proper grounding. The
use of other DIN rail materials (for example, aluminum or plastic) that can
corrode, oxidize, or are poor conductors, can result in improper or intermittent
grounding. Secure DIN rail to mounting surface approximately every 200 mm
(7.8 in.) and use end-anchors appropriately.
ATTENTION: Do not remove or replace an Adapter Module while power is
applied. Interruption of the backplane can result in unintentional operation or
machine motion.
