Rockwell Automation 1761-NET-AIC Advanced Interface Converter (AIC+) User Manual User Manual
Page 21
Publication 1761-UM004B-EN-P - June 2006
Installation and Wiring 17
1761-CBL-AS03 and 1761-CBL-AS09 Cable
1761-CBL-AM00 and 1761-CBL-HM02 Cable
1761-CBL-AS03 and 1747-CBL-AS09 Cable
Cable
Length
Connects
from
to AIC+
Interface
Converter
1761-CBL-AS03,
1761-CBL-AS09
3 m (9.8 ft),
9.9 m (29.5 ft)
SLC 500 Fixed, SLC 5/01, SLC 5/02,
and SLC 5/03 processors
RS-485
Communication
Port (Phoenix
Plug)
PanelView RJ45 port
RS-485
Communication
Port (Phoenix
Plug)
1761-CBL-AM00 and 1761-CBL-HM02 Cable
Cable
Length
Connects
External
Power
Supply
Required
Selection
Switch
Setting
from
to AIC+
Interface
Converter
1761-CBL-AM00
1761-CBL-HM02
(1)
(1)
Series B cables are required for hardware handshaking.
45 cm
(17.7 in.),
2 m
(6.5 ft)
MicroLogix
1000, 1200, and
1500
processors
RS-232 (8-pin
mini-DIN)
communication
port
No
Cable
RS-232 (8-pin
mini-DIN)
communication
port on another
AIC+ interface
converter or
MicroLogix
1100
RS-232 (8-pin
mini-DIN)
communication
port
Yes
External
1761-CBL-AS03
1761-CBL-AS09
1761-CBL-AM00
1761-CBL-HM02
