Rockwell Automation 1734-IE2C_2V POINT I/O 2 Current and 2 Voltage Input Analog Modules User Manual
Page 15
POINT I/O 2 Current and 2 Voltage Input Analog Modules 15
Publication
1734-IN027A-EN-E - May 2005
Indication
Probable Cause
Module Status
Off
No power applied to device
Green
Device operating normally
Flashing Green
Device needs commissioning due to configuration missing,
incomplete or incorrec.
Flashing Red
Recoverable fault
Red
Unrecoverable fault may require device replacement
Flashing Red/Green
Device is in self-test
Indication
Probable Cause
Network Status
Off
Device is not online
- Device has not completed dup_MAC_id test.
- Device not powered - check module status indicator
Flashing Green
Device is online but has no connections in the established state
Green
Device online and has connections in the established state
Flashing Red
One or more I/O connections in timed-out state
Red
Critical link failure - failed communication device. Device detected
error that prevents it communicating on the network.
Flashing
Red/Green
Communication faulted device - the device has detected a network
access error and is in communication faulted state. Device has
received and accepted an Identify Communication Faulted Request -
long protocol message.
