Input Map
Word Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0 Channel 0 Input Data
1 Channel 1 Input Data
2 Channel 2 Input Data
3 Channel 3 Input Data
4 Channel 4 Input Data
5 Channel 5 Input Data
6 Channel 6 Input Data
7 Channel 7 Input Data
8 H
7 H
6 H
5 H
4 H
3 H
2 H
1 H
0 L
7
L
6
L
5
L
4
L
3
L
2
L
1
L
0
9 R
7 R
6 R
5 R
4 R
3 R
2 R
1 R
0 P
7
P
6
P
5
P
4
P
3
P
2
P
1
P
0
10 Reserved Diagnostic Status
11 C
7 C
6 C
5 C
4 C
3 C
2 C
1 C
0 F
7
F
6
F
5
F
4
F
3
F
2
F
1
F
0
12 X
7 X
6 X
5 X
4 X
3 X
2 X
1 X
0 Reserved
Hn:
Ln:
Pn:
Rn:
Fn:
Cn:
Xn:
Channel n High Alarm
Channel n Low Alarm
Channel n Out Of Range Alarm
Channel n Second (Remote) Alarm
Channel n HART Failure
Channel n HART Current Fault
Channel n HART Transmitter Present
0: False 1: True
0: False 1: True
0: False 1: True
0: False 1: True
0: False 1: True
0: False 1: True
0: False 1: True
Note: Reserved data may not be shown in certain controller software
