CompactLogix ControlNet Interface Module 25
Publication
1768-IN006A-EN-P - September 2007
Red
DUPL
NODE
The module’s network
address is the same as
another module’s on the link.
1. Turn chassis power supply off.
2. Remove the module from the
chassis.
3. Set the network address switches
to a unique address, 01…99.
4. Install the module in the chassis.
5. Turn chassis power supply on if it's
off.
RACK
ERR
Cannot read backplane
EEPROM, or rack/slot
address incorrect.
Replace the chassis.
Flashing
red
BOOT
The module has invalid
firmware.
Update module firmware with
ControlFlash Update Utility.
ROM
UPDT
Flash update is in progress.
None required.
SNGL
KPR!
The module detected that it
has been connected to a
ControlNet 1.5
(single-keeper) network.
Update the module’s firmware at MAC
ID 01 and reschedule the network.
Green
OK
Normal operation.
None required.
INIT
The module is initializing.
BW
>MAX
The module is receiving too
much network traffic and
connections are timing out.
The network bandwidth has
been exceeded.
None (temporary condition).
If this happens frequently, add another
1768-CNB or 1768-CNBR module and
split the traffic between them.
Module Status Display Descriptions
Status
Display
Cause
Action
