Input Specifications
Specification
1769-IQ16
Voltage Category
24V dc (sink/source
1
)
1. Sinking/Sourcing Inputs - Sourcing/sinking describes the current flow between the I/O module and the field
device. Sourcing I/O circuits supply (source) current to sinking field devices. Sinking I/O circuits are driven
by a current sourcing field device. Field devices connected to the negative side (DC Common) of the field
power supply are sinking field devices. Field devices connected to the positive side (+V) of the field supply
are sourcing field devices. Europe: DC sinking input and sourcing output module circuits are the commonly
used options.
Operating Voltage Range
10 to 30V dc at 30°C (86°F)
10 to 26.4V dc at 60°C (140°F)
Number of Inputs
16
Bus Current Draw (max.)
115 mA at 5V dc (0.575W)
Heat Dissipation
3.55 Total Watts (The Watts per point, plus the minimum Watts,
with all points energized.)
Signal Delay (max.)
On Delay: 8.0 ms
Off Delay: 8.0 ms
Off-State Voltage (max.)
5V dc
Off-State Current (max.)
1.5 mA
On-State Voltage (min.)
10V dc
On-State Current (min.)
2.0 mA
Inrush Current (max.)
250 mA
Nominal Impedance
3K
Ω
IEC Input Compatibility
Type 1+
Power Supply Distance Rating
8 (The module may not be more than 8 modules away from the
power supply or controller.)
Input Point to Bus (Compact Bus)
Isolation
Verified by one of the following dielectric tests: 1200V ac for 1
sec. or 1697V dc for 1 sec.
75V dc working voltage (IEC Class 2 reinforced insulation)
Isolated Groups
Group 1: inputs 0 to 7
Group 2: inputs 8 to 15
Isolated groups operate in either sink or source configurations.
Input Group to Input Group
Isolation
Verified by one of the following dielectric tests: 1200V ac for 1
sec. or 1697V dc for 1 sec.
75V dc working voltage (IEC Class 2 reinforced insulation)
Vendor I.D. Code
1
Product Type Code
7
Product Code
67
