DeviceNet ArmorBlock Network Powered 16-input Module, Series A 11
Publication 1732D-IN012A-EN-E - May 2009
Communicate with Your Module
This module’s I/O is exchanged with the master through a cyclic, polled, or
change-of-state connection.
Cyclic - allows configuration of the block as an I/O client. The block will
produce and consume its I/O cyclically at the rate configured.
Polled - a master initiates communication by sending its polled I/O message
to the module. The module consumes the message, updates outputs, and
produces a response. The response has input data.
Change-of-State - productions occur when an input changes or a fault
condition occurs. If no input or fault condition change occurs within the
expected packet rate, a heartbeat production occurs. This heartbeat
production tells the scanner module that the I/O module is alive and ready to
communicate. Consumption occurs when data changes and the master
produces new output data to the I/O block.
Refer to the Module Data Definitions table for more information.
1732D-IB161212D Data Definitions
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Produce 0 I7 I6 I5 I4 I3 I2 I1 I0
Produce 1 I15 I14 I13 I12 I11 I10 I9 I8
Produce 2 In Short
Where: I=Input Data; 0=Off, 1=On
In Short 0=Working, 1=Sensor Source Voltage Fault
