4 POINT I/O
Publication 1734-IN510B-EN-P - August 2000
1734-ADN Specifications
1734-PDN Specifications
Specification Value Specification Value
Expansion I/O Capacity 12 modules (Note: Total expansion up to 63 modules
with 1734-EP24DC) Input Overvoltage
Protection Reverse polarity protected
DeviceNet Communication
Rate 125K bit/s (500m maximum)
250K bit/s (250m maximum)
500K bit/s (100m maximum) DeviceNet Cable Allen-Bradley part number 1485C-P1-Cxxx
Refer to publication DN-2.5 for more information
Module Location Starter module - left side of 1734 system Input Voltage Rating 24V dc nominal
Power Supply Note: In order to comply with CE Low Voltage
Directives (LVD), you must use a Safety Extra Low
Voltage (SELV) or a Protected Extra Low Voltage (PELV)
power supply to power this adapter. Indicators 3 red/green status indicators
Adapter status
DeviceNet status
PointBus status
2 green power supply status indicators:
System Power (PointBus 5V power)
Field Power (24V from field supply)
DeviceNet Input Voltage
Range 11-25V dc DeviceNet specification DeviceNet Power
Requirements 24V dc (+4% = 25V dc max) @ 30mA maximum
Power Consumption 8.1W maximum @ 28.8V dc Isolation Voltage 1250V rms/V ac
Power Dissipation 2.8W maximum @ 28.8V Thermal Dissipation 9.5 BTU/hr maximum @ 28.8V dc
Field Power Bus
Nominal Voltage
Supply Voltage Range 24V dc
10-28.8V dc range,
Dimensions Inches
(Millimeters)
3.0H x 2.16W x 5.25L
(76.2H x 54.9W x 133.4L)
Supply Current 10A maximum Mass 9.0 oz/255 grams
Field Wiring Terminations
DeviceNet
1 - Black Wire V
2 - Blue Wire CAN Low
3 - Bare Wire Shield
4 - White Wire CAN High
5 - Red Wire +V
Field Wiring Terminations
Power Supply 0 - No Connection 1 - No Connection
2 - Chassis Ground 3 - Chassis Ground
4 - Common 5 - Common
6 - Supply 7 - Supply
Power Supply Specifications
Power Supply Note: In order to comply with CE Low Voltage
Directives (LVD), you must use a Safety Extra Low
Voltage (SELV) or a Protected Extra Low Voltage (PELV)
power supply to power this adapter. Interruption Output voltage will stay within specifications when
input drops out for 10ms at 10V with maximum load.
Input Voltage Rating 24V dc nominal
10-28.8V dc range Field Side Power
Requirements 24V dc (+20% = 28.8V dc maximum) @ 400mA
maximum
Inrush Current 6A maximum for 10ms PointBus Output Current 1A maximum @ 5V dc ±5% (4.75 - 5.25)
Input Overvoltage Protection Reverse polarity protected
Specification Value: Specification Value:
Expansion I/O Capacity 12 modules Module Location Starter module - left side of 1734 system
Communication Rate 125K bits/s (500m max)
250K bits/s (250m max)
512K bits/s (100m max) Indicators 2 green power supply status indicators
System power (PointBus 5V power)
DeviceNet power (24V from DeviceNet)
DeviceNet Power Req. 24V dc (+4% = 25V dc max @ 400mA max Dimensions (HxWxL) 76.2mm x 25.4mm x 133.4mm (3.0in x 1.0in x 5.25in)
DeviceNet Cable Allen-Bradley PN 1485C-P1-Cxxx
Refer to publication DN-2.5 Input Overvoltage
Protection Reverse polarity protected
Power Supply Note: In order to comply with CE Low Voltage
Directives (LVD), you must use a Safety Extra Low
Voltage (SELV) or a Protected Extra Low Voltage (PELV)
power supply to power this interface. Field Power Bus
Voltage
Current
10V to 28.8V dc,
120V ac or 240V ac
10A max
Field Wiring
Power Supply
0 - No connection 4 - Common
1 - No connection 5 - Common
2 - Ground 6 - Supply
3 - Ground 7 - Supply
Field Wiring Terminations
DeviceNet
1 - Black -V 4 - White CAN High
2 - Blue CAN Low 5 - Red +V
3 - Bare Drain
Input Voltage Rating 24V dc nominal Power Dissipation 1.2W max @ 25V
Input Voltage Range 11-25V dc DeviceNet specification Thermal Dissipation 4.1 BTU/hr max @ 25V dc
