Rockwell Automation 1791-32AO SERIES B 32 Input AC Block I/O Module - Manual (Page 3)

Installation Instructions
Block I/O
Cat. No. 1791-32A0 Series B
3
Table A
Acceptable Wiring Cables for Block I/O Connection
Use Cable Type
Remote I/O link Belden 9463
Input and output wiring
Up to 14AWG (2mm 2 ) stranded with
3/64 inch (1.2mm) insulation
Connect wiring as shown in Figure 4 or Figure 5.
Figure 4
Wiring Connections with PLC Family Programmable Controllers (refer
to Table B)
L2/N L1
RIO
1
30
PLC
NOT
USED
NOT
USED
NOT
USED
NO
CONN
NO
CONN
NO
CONN
NO
CONN
NO
CONN
30
1
GND
BLU
CLR
in 00
in 01
in 02
in 03
in 04
in 05
COM
1
NOT
USED
COM
1
COM
1
in 11
N
SHD
COM
2
in 10
in 12
in 13
in 14
in 15
in 16
in 17
COM
2
NOT
USED
COM
2
L1
in 07
in 06
in 00
in 01
in 02
in 03
in 04
in 05
in 10
in 12
in 13
in 14
in 15
in 16
in 17
in 07
in 06
in 11
COM
3
COM
3
COM
3
COM
4
COM
4
COM
4
COM 1 connections are internally connected together.
COM 2 connections are internally connected together.
COM 3 connections are internally connected together.
COM 4 connections are internally connected together.
1
2
29
30 1
2
29
30
L1
L2/N
L1
L2/N
L1
L2/N
L1
L2/N
NOTE:
