MicroLogix™ 1100 Replacement Battery 11
Publication 1763-IN003A-EN-P - August 2005
Installing Lithium Battery (1763-BA)
For battery installation or replacement do the following:
.
1. If you are replacing an old battery, unplug the existing battery connector. The figure
on page 10 shows the battery connector location.
2. Remove the battery from the retainer clips.
3. Insert a new or replacement battery in the holder making sure it is held in by the
retainer clips.
4. Plug the battery connector into the socket.
5. Secure the battery wires along the wire guide.
IMPORTANT
When the controller’s Battery Low indicator is lit, check whether the
battery wire connector is connected correctly or replace the
replaceable battery with a new one immediately. When the indicator
turns on, it means that either the battery wire connector is
disconnected, or the battery will last for at most 2 weeks if it is
connected.
