Before you begin, 6 point i/o 220v ac input module publication – Rockwell Automation 1734-IM2_IM4 POINT I/O 220V AC Input Module User Manual
Page 6
6 POINT I/O 220V ac Input Module
Publication
1734-IN008C-EN-E - January 2007
Before You Begin
Note that this series C product can be used with the following:
• DeviceNet and PROFIBUS adapters
• ControlNet and EtherNet/IP adapters, using RSLogix 5000
software, version 11 or later
See the figures to familiarize yourself with major parts of the module,
noting that the wiring base assembly is one of the following:
• 1734-TB or 1734-TBS POINT I/O two-piece terminal base,
which includes the 1734-RTB removable terminal block
• 1734-TOP or 1734-TOPS POINT I/O one-piece terminal base
120/220V
AC
Ou
tpu
t
M
odule
Status
Netw
ork
Status
NO
DE
:
0
1
4182OA
1734-TB or 1734-TBS
Mounting Base
Removable
Terminal
Block with
Screw or
Spring Clamp
Insertable
I/O Module
Module Locking
Mechanism
Slide-in Writable Label
Interlocking
Side Pieces
DIN Rail Locking Screw (orange)
Module
Wiring
Diagram
Mechanical
Keying (orange)
Removable Terminal
Block Handle
