12 ArmorBlock MaXum 16 Sinking Output Module Series B
Publication 1792D-IN041B-EN-P - September 2000
Specifications
16 Output Module - Cat. No. 1792D-OVT16E
Max. Min.
Outputs per block 16 sinking outputs labeled 00 through 15
Output Auxiliary Voltage 30V 10V
On-state Voltage Drop 1V -
On-state Current 0.3A -
Off-state Leakage 1.5mA -
Module Current (all outputs) 4.0A -
Surge Current - for 10 ms,
repeatable every 2s 0.6A -
Indicators Net/Mod Status - red/green
Auxiliary Power - green
Logic Status - red/green
Point LED - yellow/orange/red
Communication Rate
•125Kbps @ 500 meters (1600 feet) for thick cable,
flat media length 375 meters (1230 feet)
•250Kbps @ 200 meters (600 feet) for thick cable,
flat media length 150 meters (492 feet)
•500Kbps @ 100 meters (330 feet) for thick cable,
flat media length 75 meters (246 feet)
DeviceNet Power: Voltage
Current 25V dc max
125mA 11V dc min
250mA
Auxiliary Power: Voltage
Current 30V dc
4A 10V dc
4A
Dimensions (assembled to base)
inches - (millimeters) 1.9H x 2.7W x 6.85D
(48.26)H x (68.6)W x (174)D
Environmental Conditions
Operational Temperature
Storage Temperature
Relative Humidity
Shock Operating
Non-operating
Vibration
-25 to 60
o
C (-13 to 140
°
F)
-25 to 80
o
C (-13 to 176
°
F)
Up to 100%
30g peak acceleration, 11 (+1) ms pulse width
50g peak acceleration, 11 (+1) ms pulse width
Tested 10g @ 10-500 Hz per IEC 68-2-6
Conductors Publication DN-6.7.2
