Labeling for the 1492 interface module – Rockwell Automation 1769-IQ32T Compact Module User Manual
Page 13

Compact 32-point 24V dc Sink/Source Input Module 13
Publication 1769-IN072A-EN-P - June 2005
Labeling for the 1492 Interface Module
Several different stick-on label sets are provided on a single card with 1492 Interface Modules.
Each label set is identified with an I/O module catalog number and words “upper” and
“lower” to identify which terminal strip the label should be affixed to.
The table on the following page identifies the 1769-IQ32T 32-point labels and their location
on the interface module. Peel off the appropriate label and apply it to the interface module.
The stick-on labels of the 1492 Interface Module are abbreviated as follows: +V1 = V dc 1,
+V2 = V dc 2, CM1 = Com 1, etc.
NOTE: If the stick-on label set for the 1769-IQ32T module is not available, use the 1492
interface module stick-on label set for 1746-IB32 modules.
Terminal Block Labels
Bottom Terminal Block
Top Terminal Block
CM1
CM1
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
CM2
CM2
CM3
CM3
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
CM4
CM4
TIP
If you decide to build your cable using another 1746-N3 to terminate
the cable at the 1492 Interface Module end, wire it in the following
manner: Pin 1 to Pin 1, Pin 2 to Pin 2, Pin 3 to Pin 3, etc.
