MicroLogix 1762-OV32T Solid State 24V DC Sink Output Module 17
Publication 1762-IN021B-EN-P - July 2013
Specifications
General Specifications
Attribute
Value
Number of outputs
32
Dimensions, HxWxD
90 x 40.4 x 87 mm (3.54 x 1.59 x 3.43 in.)
Shipping weight, approx.
200 g (7.05 oz)
Bus current draw, max
175 mA @ 5V DC
0 mA @ 24V DC
Heat dissipation
2.7 W @ 26.4 V DC
Wire size
22, 24, 26 AWG solid or stranded copper wire rated @ 90 °C (194 °F)
Wiring category
(1)
(1)
Use this Conductor Category information for planning conductor routing. Refer to Industrial Automation Wiring and
Grounding Guidelines, publication
.
2 - on signal ports
Pilot duty rating
Not rated
Enclosure type rating
IP20
North American temp code
T3C
Output Specifications
Attribute
Value
Isolated groups
Group 1: Outputs 0...15
Group 2: Outputs 16...31 (internally connected to common)
Output group to backplane isolation
Verified by one of the following dielectric tests:
1200V AC for 2 s or 1697V DC for 2 s.
75V DC working voltage (IEC Class 2 reinforced insulation)
Vendor I.D. code
1
Product type code
7
Product code
102
Voltage category
24V DC sink
Operating voltage range
10.2...26.4V DC
Signal delay, max resistive load
Turn-on = 0.5 ms
Turn-off = 4.0 ms
On-state current, min
1.0 mA
Off-state leakage current, max
0.1 mA @ 26.4V DC
On-state voltage drop, max
0.3V DC @ 0.5 A
Continuous current, per point, max
0.5A @ 60 °C (140 °F)
