Rockwell Automation 1792-OB8PLP INSTL INSTR 8 OUTPUT MODULE User Manual
Page 11

ArmorBlock-LP 8 Output Module
11
Publication 1792-5.7 – December 1997
General Specifications
DeviceNet PowerVoltage
Current
11.0 – 25.0V dc
100mA
Dimensions
Inches
Millimeters
6.8H X 2.4W X 2.0D
172.1H X 60W X 51D
Environmental Conditions
Operational Temperature
Storage Temperature
Relative Humidity
Shock
Operating
Non-operating
Vibration
0 to 60
o
C (32 to 140
o
F)
–20 to 80
o
C (–4 to 176
o
F)
up to 100%
30 g peak acceleration, 11(+1)ms pulse width
50 g peak acceleration, 11(+1)ms pulse width
Tested 10 g @ 10–500Hz per IEC 68-2-6
Conductors
Refer to publication 1485-6.7.1 for information on
cabling for your DeviceNet module.
Enclosure
Meets or exceeds IP67
Agency Certification
(when product is marked)
•
CE marked for all applicable directives
This product has been tested at an Open DeviceNet Vendor
Association, Inc. (ODVA) authorized independent test laboratory
and found to comply with ODVA Conformance Test Software
Version FT 1.3/1.1.
