Rockwell Automation 1667-Z32F PanelConnect Fuse Module - Manual (Page 4)

41063-173-01 (2)
Printed in U.S.A.
5 x 20 mm (.125A, 250V Fast Acting)
5 x 20 mm (Action rapide 0,125 A, 250 V)
5 x 20 mm (12. 0,125 A, 250 V, flink)
5 x 20 mm (12. 125 A, 250 V ad azione rapida)
5 x 20 mm (12. 0.125 A, 250 V, de acción rápida)
LITTELFUSE 217.125
BUSSMANN GDB-125MA
WICKMANN 19193-028-I1
Fuse Removal
Retrait du fusible
Entfernung der Sicherung
Rimozione del fusibile
Extracción de fusibles
1
