Rockwell Automation 1792D-8BVT8D ArmorBlock MaXum 8 Input/8 Output Module Series B - Manual (Page 12)

12 ArmorBlock MaXum 8 Input / 8 Output Module Series B
Publication 1792D-IN020B-EN-P - September 2000
Specifications
8 Input / 8 Output Module - Cat. No. 1792D-8BVT8D
Input Specifications Max. Min.
Inputs per block 8 - 3 wire or dry contact PNP or NPN devices or 4 -
4 wire PNP or NPN devices
Sensor Source Current (per
connector) 100mA total -
Off-Wire Sense Current 0.5mA -
On-state Voltage 25V dc 10V dc
On-state Current 10mA 2mA
Off-state Voltage 5V dc -
Off-state Current - 1.5mA
Output Specifications Max. Min.
Outputs per block 8 sourcing outputs labeled O0 through O7
Off Peak Blocking Voltage 30V 10V
On-state Voltage Drop 1V -
On-state Current 0.5A -
Off-state Leakage 1.5mA -
Module Current (all outputs) 4.0A -
Surge Current - for 10ms,
repeatable every 2s 2.4A -
No Load Sense Current (On-state) 0.18A -
General Specifications
Indicators Net/Mod Status - red/green
Logic Status - red/green
Auxiliary Power - green
Point LED - yellow/orange/red
Communication Rate
•125Kbps @ 500 meters(1600 feet) for thick cable,
flat media length 375 meters (1230 feet)
•250Kbps @ 200 meters(600 feet) for thick cable,
flat media length 150 meters (492 feet)
•500Kbps @ 100 meters (330 feet) for thick cable,
flat media length 75 meters (246 feet)
DeviceNet Power Voltage
Current
Refer to the graphs in the
Overview section of the
ArmorBlock I/O Family Technical
Data, pub. no.
1792-TD001B-EN-P. 25V dc max
150mA max (no sensors) 11V dc min
up to 1.4A (8 sensors
@ 50mA per sensor)
