Compact I/O 1769-ADN DeviceNet Adapter 23
Rockwell Automation Publication 1769-IN001C-EN-P - February 2013
Input/Output Specifications
Enclosure Type Rating
None (open-style)
Certifications (When Product is Marked)
c-UL-us UL Listed for Class I, Division 2 Group A,B,C,D
Hazardous Locations, certified for U.S. and Canada
CE
1
European Union 89/336/EEC EMC Directive,
compliant with:
- EN 50082-2; Industrial Immunity
- EN 61326; Meas./Control/Lab., Industrial Requirements
- EN 61000-6-2; Industrial Immunity
- EN 61000-6-4; Industrial Emissions
C-Tick
1
Australian Radiocommunications Act, compliant with:
- AS/NZS 2064; Industrial Emissions
ODVA
conformance tested to DeviceNet specifications
1
See the Product Certification link at
for Declarations of Conformity, Certificates, and other certification details.
Specification
Value
Bus Current Draw (Maximum)
Series A
450mA at 5V dc (2.25W)
Series B
500mA at 5V dc (2.5W)
Heat Dissipation
4.7W maximum
I/O Capacity
30 modules
Communication Rate
125k bit/s
250k bit/s
500k bit/s
Indicators
Module status
- red/green
Network status
- red/green
I/O status
- red/green
Diagnostic status - red/green
DeviceNet Power Requirements
24V dc (+4%) @ 90mA maximum, N.E.C. Class 2
DeviceNet Cable
Allen-Bradley part no. 1485C-P1-Cxxx. Refer to publication DN-2.5 for more
information.
Power Supply Distance Rating
4 (Series A); 5 (Series B)
(The adapter may not be more than 4 or 5 modules away from the power supply,
depending on the Series.)
Isolation Voltage
Verified by the following qualification test:
710V dc, 1 minute
Vendor I.D. Code
1
Product Type Code
12
Product Code
69
