IV. Conversion Module Specifications
(Operating specifications are when installed in the Conversion System base / cover-plate assembly)
III. Compatibility
1771
Analog I/O Module
1756
Analog I/O Module
1492
I/O Conversion Module
1492
Cable
1771-IFE (SEC) 1771-IF16 (SEC) 1492-CM1771-LA001 1492-CONACAB005B
1771-IFF (SEC) 1771-IF16 (SEC) 1492-CM1771-LA001 1492-CONACAB005B
1771-IFF (SEV) 1771-IF16 (SEV) 1492-CM1771-LA001 1492-CONACAB005A
1771-IFE (SEV) 1771-IF16 (SEV) 1492-CM1771-LA001 1492-CONACAB005A
Foot Notes:
To understand any issues concerning I/O module compatibility, refer to the Installation Manuals for the specific
1771 and 1756 I/O modules involved.
The 3 numbers indicate the length of the 1492 Cable. Recommended cable lengths of 0.5M are shown.
Additional cable lengths are as follows:
1.0M = 1492-CONACAB010A
1.0M = 1492-CONACAB010B
Specification
Dimensions 11.81 in. (height) x 4.38 in. (depth) x 1.5 in. (width)
300 mm. (height) x 111.25 mm (depth) x 38.1 mm (width)
Storage Temperature -40 to +85°C (-40 to +185°F)
Operating Temperature 0 to 60°C (32 to 140°F)
Operating Humidity 5 to 95% at 60°C (non-condensing)
Shock
Non
-
operating
Operating
50g
30g
Operating Vibration 2g at 10 to 500Hz (Agrees with 1756 I/O module specifications)
Maximum Operating Voltage 30 Vdc
Max. Module Operating Current
Per Point:
Per Module:
2 Amps
12 Amps
Agency Certifications UL Classified: Under UL File Number E113724
CSA
CE: compliant for all applicable directives
Pollution Degree 2
Environmental Rating IP20
Refer to the Wiring Diagram(s) for
current limits for a specific configuration. NOTICE
Value
Approximate Shipping Weight 250.6 g (0.55 lbs) (includes carton)
