2 Interface Board – Instruction Sheet
Identification
Verify the catalog number of the interface board.
Table 1 – Interface Board Catalog Number
System Voltage
Control Circuit Voltage
and Frequency
Catalog Number
800V to 6900V
110/120 to 220/240 VAC
50/60 Hz
1503E-INTB
Note: The following items are supplied with the Interface Board:
• Connectors 80174-014-01 and 80174-014-02
• Ribbon cable assembly 80026-146-53
• Interface cables (6-pin) 80174-201-01 (Qty 2), and (8-pin) 80174-201-02 (Qty 3)
• Mounting bracket, stand-offs and screws
Storage
If the interface board will not be installed immediately after receipt,
store it in a clean, dry and dust-free environment. Humidity should
not exceed 95%, non-condensing.
Installation
Refer to MV SMC Flex OEM Components – Bulletin 1503E,
Installation Instructions (Publication 1503E-IN001_-EN-P) for
complete installation instructions of the Interface Board.
Additional Publications
To order additional copies of Instruction Manuals for all Rockwell
Automation medium voltage products, please contact a Rockwell
Automation sales office or your local distributor.
Medium Voltage Products, 135 Dundas Street, Cambridge, ON, N1R 5X1 Canada, Tel: (1) 519.740.4100, Fax: (1) 519.623.8930, www.ab.com/mvb
Publication 1503E-IN002C-EN-E – May 2008
Copyright © 2008 Rockwell Automation, Inc. All rights reserved. Printed in Canada.
Supersedes Publication 1503E-IN002B-EN-P – January 2006
