Cables and connector kits, Shaft seal kits – Rockwell Automation N-Series Brushless Servo Motor User Manual
Page 13
N-Series Motor Installation Instructions 13
Publication 1398-IN519A-EN-P — March 2001
Cables and Connector Kits
Factory manufactured cables are available in standard cable lengths. If
you choose to build your own cables, the following connector kits are
available for connecting N-Series motors.
Shaft Seal Kits
N-Series motors equipped with a shaft seal will have an IP65
environmental rating. The following shaft seal kits are available for
N-Series motors.
Catalog Number
Description
2090-NPC-S
Straight Power Connector Kit
2090-NFC-S
Straight Feedback Connector Kit
2090-NBC-S
Straight Brake Connector Kit
Catalog Number
Description
0041-5056
Shaft Seal Kit for N-2300 Series Motors
0041-5065
Shaft Seal Kit for N-3400 Series Motors
0041-5058
Shaft Seal Kit for N-4200 Series Motors
0041-5059
Shaft Seal Kit for N-5600 Series Motors
