Rockwell Automation 1492-XIMTSxxxx_RXIMTSxxxx 16 and 32 Point Relay Interface Modules User Manual
Page 5

WARNING: Explosion Hazard.
Do not disconnect equipment unless power has been switched off or the area is known to be non-hazardous.
This equipment is suitable for use in Class I, Division 2, Groups A,B,C and D or non-hazardous locations only.
Substitution of components may impair
suitability for Class I, Division 2. Power, input and output (I/O) wiring must be in accordance with Class I, Div. 2 wiring methods - Article 501 - 10 (B) (1)
of the National Electrical Code.
PN-90363
DIR 10000135242 (Version 01)
Publication 1492-IN103B-MU-E
(5)
Relay Contact Rating
Spécification du Contact à Relais
700-TBS24
Relaiskontakt-Nennwerte
Classificazione Contatti di Relay
Capacidad Nominal del Contacto de Relé
Maximum Module Current
·
0.75 Amp per relay output
Replacement Relays
·
24VDC Control Voltage: 700-TBS24
Electrical Ratings
ORDINARY LOCATIONS
HAZARDOUS LOCATION
0.75 A DC Ta 0°C - 40°C
0.5 A DC Ta 0°C - 50°C
Output
Rated Insulation Voltage (Ui )
250V IEC, 300V UL/CSA
1-Pole, 1 N.O. 1A
Rated Thermal Current (I th )
Load Voltage Range
0...24VDC
max. 100μA (@U=24V)
33 V
Max. Switching Current
Max. Repetitive Blocking Voltage
On State Voltage Drop @ Max.
Switching Current
< 120mVDC
Leakage Current
Ind. Cont. Eq. for Haz. Loc.
Listed A196
Class I, Div.2, Groups A,B,C,D
Class I, Zn2, Groups IIC
Listed Ind. Cont. Eq. A191
