10. Status of the D-Cine Premiere DP100
10. STATUS OF THE D-CINE PREMIERE DP100
Status lights
On top of the projector head, rear side, status lights are built-in in the corners. When no errors, e.g. fan failure, overheating.. are
detected, the color of the status lights is GREEN. When an error occurs, the color of the status lights changes to RED. Information
about the type of error can be retrieved using the D-Communicator or the Touch panel menu.
If you are not familiar with the projector, call for technical assistance.
A
Image 10-1
Status lights on projector head
10.1 Start up of the status function
How to start up
1. Push Home . (image 10-2)
The home menu opens. (image 10-3)
2. Push Status. (image 10-4)
The status menu will be displayed. (image 10-5)
Image 10-2
Start up screen Image 10-3
Main menu
R5976907 D-CINE PREMIERE DP100 02/11/2005 33
