1. Remove power from the drive.

2. Open the Enclosure door.

3. Check for zero volts at:

+DC/-DC Brake Terminals

terminals R-L1, S-L2, and T-L3 on TB1

4. Check for the absence of control voltage at:

terminals V+ and V- on TB11 on the Main Control Board

TB20 and TB21 on drives using a PLC Comm Adapter Board

TB5, TB6, and TB7 on drives using a Standard Adapter
Board

TB3 on drives using a Control Interface L-Option Board

5. Remove the four nuts fastening the High Voltage Guard to the

standoffs.

6. Pull the guard away from the drive.

Drive shown with door open, sides removed.
