Rockwell Automation 1495-N69 Protective Fuse Cover User Manual
Page 3
Locate and drill holes if fuse blocks are not located directly
under the disconnect switch.
Bulletin 1491 Separately Mounted Fuse Block Protective Fuse Cover Installation
PN-39671
DIR 10000033845
(Version 00)
1
14”
A
3-1/2”
7”
Optional
Mounting
Holes
3-1/2”
5/16”
4”
5”
17-1/8”
(4) - .218 Dia.
Holes for #1/4 - 20
Thread Forming Screws
5”
+.002
-.001
A
8-1/8”
250V Class H, R
11-1/8”
600V Class H, R
600 A Fuses
