V. Wiring Diagrams
(4)
Conversion Module Installation and Application Considerations
The 1771-OBN module output current limits versus 1756-OB32 limits are as follows:
1771-OBN
1756-OB32w/1492-CONCAB005Z
a) Current/Point
0.5A
0.35A @ 60˚C
b) Current/Module
8A
6A @ 60˚C
c) Surge Current/Point
2A for 10ms
1A for 10ms
The 1771-OBN has four (4) 4A, 250V rectifier fuses. The 1756-OB32 is NOT fused, as such four (4) 2AG fuse clips and 4A
fuses are provided on the 1492-CM1771-LD009F conversion module.
The 1492-CONAB005Z is limited to 3A per pin.
The 1771-OBN has 4 groups (allowing 4 separate power supplies) and the 1756-OB32 has 2 groups. This module/cable
combination ties Groups 0 & 1 from the 1771-OBN to Group 0 on the 1756-OB32 and Groups 2 & 3 from the 1771-OBN to
Group 1 on the 1756-OB32. Field wiring modification must be made to accommodate this if multiple supplies were used.
If 4 supplies were used, 2 must be removed.
Refer to your 1771-OBN and 1756-OB32 Installation Manual wiring schematics and diagrams for more details. Ensure
1756 output module ratings are not exceeded.
[Reference Doc: 41170-938 (Version 01)]
There are several key application considerations and system specifications (bottom of drawing) when
using these components (conversion module, cable and input module). Read and understand these
considerations before installation.
WARNING
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
Black
White
Red
Green
Orange
Blue
White/Black
Red/Black
Green/Black
Orange/Black
Blue/Black
Black/White
Red/White
Green/White
Blue/White
Black/Red
White/Red
Orange/Red
Blue/Red
Red/Green
Orange/Green
Black/White/Red
White/Black/Red
Red/Black/White
Green/Black/White
Orange/Black/White
Blue/Black/White
Black/Red/Green
White/Red/Orange
Red/Black/Green
Green/Black/Orange
Orange/Black/Green
Blue/White/Orange
Black/White/Orange
White/Red/Orange
Orange/White/Blue
White/Red/Blue
LOAD
+
-
10-30V dc(0)
10-30V dc(1)
10-30V dc(2)
10-30V dc(3)
18
36
1
19
2
20
3
21
4
22
5
23
6
24
7
25
8
26
9
27
10
28
11
29
12
30
13
31
14
32
15
33
16
34
17
35
1
11
21
31
2
22
3
23
4
24
5
25
6
26
7
27
8
28
9
29
12
32
13
33
14
34
15
35
16
36
17
37
18
38
19
39
10
20
30
40
DC-0(+)
DC-1(+)
OUT-0
OUT-16
OUT-1
OUT-17
OUT-2
OUT-18
OUT-3
OUT-19
OUT-4
OUT-20
OUT-5
OUT-21
OUT-6
OUT-22
OUT-7
OUT-23
OUT-8
OUT-24
OUT-9
OUT-25
OUT-10
OUT-26
OUT-11
OUT-27
OUT-12
OUT-28
OUT-13
OUT-29
OUT-14
OUT-30
OUT-15
OUT-31
RTN OUT-0
RTN OUT-1
Output 00
Output 00
Output 01
Output 01
Output 02
Output 02
Output 03
Output 03
Output 04
Output 04
Output 05
Output 05
Output 06
Output 06
Output 07
Output 07
Output 10
Output 10
Output 11
Output 11
Output 12
Output 12
Output 13
Output 13
Output 14
Output 14
Output 15
Output 15
Output 16
Output 16
Output 17
Output 17
Common 0
Common 1
Common 2
Common 3
PN-114281
DIR 10000060092 (Version 01)
Publication 1492-IN039B-EN-E
Conversion: 1771-OBN to 1756-OB32
Conversion Module
1492-CM1771-LD009F
Cable
1492-CONCAB005Z
1756-OB32
1771-WN Swing Arm
