1326AB Resolver Feedback Package
Instructions
4. Attach the gasket to the resolver housing.
5. If the resolver is being mounted to a 1326AB-Bxx or Cxx series
servomotor, the 1326AB-MOD-Mxx Mounting Adapter must be
installed at this point.
6. Insert the resolver shaft into the coupling. Fasten the resolver housing
to the motor using the three screws and lockwashers supplied.
7. Remove the plastic plugs from the two threaded resolver ports. Rotate
the coupling in relation to the unfastened shaft, allowing the coupling
to seek a normal resting position.
Important: Assure that the coupling is not compressed or stretched
after it has reached its normal aligned position.
8. Fasten the coupling to the resolver shaft through the port(s).When
tightening, use no more than 16-18 lb.-in. (1.8-2.0 N-m) of torque.
Assure that light can clearly be seen between all coupling spacings.
9. Connect the appropriate Allen-Bradley 1326-CVU cable to the
threaded resolver connector.
10. Check for proper operation.
