1391B-ES / C-HB / D Board Replacement

Instructions

Figure 1
1391ES-AQB Board Set

Remove Lower
Ribbon Cable

TB1 – Remove Cable/Connector

TB2 – Remove Cables/Connectors

Do Not Remove
Upper Ribbon Cable

Standoffs

Squeeze the 8 Standoffs

to Release the Board Set

TB3 –

Remove Cable/Connector

5. Squeeze each of the eight standoffs located on the bottom Logic

Control Board to release the board set from the chassis.

6. Position the new board set onto the standoffs. Push down on the board

set until all of the standoffs have snapped into place.

7. Replace the connectors and cables previously removed.

8. Perform the Start-Up Procedure as outlined in the appropriate

Instruction Manual.

Publication 1391ES-6.0 – June, 1992

P/N 151595
