Rockwell Automation 1492-AIFM8-3_RAIFM8-3 Analog Interface Modules User Manual
Page 2
(2)
Removable Terminal Block
Installation / Removal
Montage / Retrait
Installation / Entfernen
Montaggio / Smontaggio
Instalación / Extracción
Module
Installation / Removal
Montage / Retrait
Installation / Entfernen
Montaggio / Smontaggio
Instalación / Extracción
1
2
3
0.32 in
(8 mm)
3.5-4.5 lb-in
(0.38-0.50 Nm)
1492-N90
1492-N90
#22-#12 AWG
(0.2-4 mm
2
)
Cu only
Cuivre seulement
Nur Kupfer
Solo Cu (rame)
Solamente Cu
1
2
3
0.32 in
(8 mm)
#22-#12 AWG
(0.2-4 mm
2
)
Cu only
Cuivre seulement
Nur Kupfer
Solo Cu (rame)
Solamente Cu
3.5-4.5 lb-in
(0.38-0.50 Nm)
Applies to modules with fixed and
removable (R) terminal block
Applies to modules with
removable terminal block plugs (1492-RAIFM_)
W
H
PN-104504
DIR 40063-326 (Version 11)
