Rockwell Automation 198E-C0C4R Plastic Encl. for DOL and Rev. Starters with Motor Protection C.B. - Manual (Page 4)

DIR 10000248718 (Version 03)
Printed in Estonia
125 [4.93] 32.5 [1.28] 125 [4.93]
250 [9.85]
50 [1.97]
50 [1.97]
125 [4.93]
50 [1.97]
24 [0.95]
Ш23
[Ш0.91]
3.5
[0.14]
13 [0.51]
Ш15
[Ш0.59]
Ш3.5
[Ш0.14]
150 [5.91] 159.3 [6.28]
38.7 [1.52]
95 [3.74]
14.1 [0.56]
14.1 [0.56]
14.1
[0.56]
14.1
[0.56]
28.1 [1.11]
2 x 1...6 mm²
2 x No. 14...10 AWG
Pozidriv No. 2
2.3 Nm
20 lb-in
Pozidriv No. 2
2.0 Nm
18 lb-in
(1.2 x 6.5)
10
2 x 1...6 mm²
2 x No. 14...10 AWG
110 [4.33]
235 [9.26]
Rotary operator alternatively
(for maintained control)
Impulse Control, Multi Function Push Button Maintained Control, Selector Switch < O >
SUPPLY CONDUCTOR
SIZE (AWG)
BONDING CONDUCTOR
QTY. SIZE
FOR USE WITH ALLEN-BRADLEY
GROUNDING ADAPTER KIT, CAT. NO. 198-GR1
SEE APPLICABLE CODES AND LAW
FOR GROUNDING REQUIREMENTS
14
12
10 14
12
12 1
1
2
Schematic Diagram
Dimensions
1 1
1
1
1
1 L1 control voltage supplied from external source.
L1
I I 3 2 1
1- HAND
2- OFF
3- AUTO
A1
A2
2 WIRE
CONTROL
Illuminated HOA Selector Switch
L1
1
WARNING: Bonding between metallic conduits must be provided.
AVERTISSEMENT: Une liaison électrique doit être assurée entre les
conduits métalliques.
