Rockwell Automation 800T-N310_N310J_N310L_NX1320 Protective Ring for Push-Pull Push Button User Manual
Page 2

PN-18314
DIR 10000008197 (Version 01)
Copyright © 2013 Rockwell Automation, Inc. All Rights Reserved. Printed in USA.
Allen-Bradley, Rockwell Software, and Rockwell Automation are trademarks of Rockwell Automation, Inc.
Trademarks not belonging to Rockwell Automation are property of their respective companies.
Publication 800T-IN014B-MU-P - August 2013
New Installation
Nouvelle installation
Neumontage
Instalación nueva
Instalação nova
16 Gage - 1/16 (1.6)
t
3
2
1
12 Gage - 7/64 (2.8)
10 Gage - 9/64 (3.6)
3/16 (4.8)
N
> 3/16 (4.8)
Panel Thickness
Épaisseur du panneau
Plattenstärke
Grosor del panel
Espessura do painel
Number of gaskets
Nombre de joints d'étanchéité
Anzahl der Dichtungen
Cantidad de juntas
Número de juntas
t
(Counterbore)
(Alésage)
(Flachsenkung)
(Escariado)
(Rebaixo)
800T-N310*
or
800T-NX1320
800T-N310*
or
800T-NX1320
800T-N310*
or
800T-NX1320
Jumbo or Automotive
Plaque géante ou pour automobile
Jumbo oder Kfz
Jumbo o de industria automotriz
Jumbo ou Automotiva
50 - 60 lb-in
5.6 - 6.8 N•m
inch (mm)
+
--
N
Guard - Operator Compatibility Table
Protection – Tableau de compatibilité de l'opérateur
Kontrolle – Kompatibilitätstabelle für Anwender
Tabla de compatibilidad Protección - Operador
Proteção – Tabela de compatibilidade do operador
800T-N310, -NX1320
800T-N310J
800T-N310L
800H-FRX*
800T-FX*
800H-FRXJ*
800T-FXJ*
800T-FXL*
