40752-021(1) Effective 3/02
10 in -lb
(0.2 N m )
⋅
R E S E T
P U S H
TO TR IP
O F F
TR IP
O N
3
4
5
S ee Tab le
Catalog Wire Terminal Body
Number AWG mm 2 in.-lb N-m Type Material
140U-J-TLS * 4-350 25-185 180 20 Cu STAINLESS STEEL
140U-J-TLA 4-350 25-185 250 28 Cu/Al ALUMINUM
* Standard collars mounted on line and load end
Wire Size Range Torque
6
M agnetic A djustm ent
M a g n e tic
A d ju s t
T h e rm a l
A d ju s t
Motor Circuit Protection
Line Protection
Molded Case Switch (Isolation)
N e u tra l P o le
A d ju s t
4 P 3 d (0 % )
4 P 4 d (1 0 0 % )
o r
4 P 4 d n /2 (6 0 % )
M a g n e tic
A d ju s t
T h e rm a l
A d ju s t
Mounting Operation
Connections Trip Unit
Endcap
Terminal
