Rockwell Automation 140U-xxx J-Frame C.B. for Variable Depth Rotary Handle Mech. - Manual (Page 4)

PN-188947
DIR 10000484010 (Version 00)
Copyright © 2013 Rockwell Automation, Inc. All Rights Reserved. Printed in USA.
Allen-Bradley, Rockwell Software, and Rockwell Automation are trademarks of Rockwell Automation, Inc.
Trademarks not belonging to Rockwell Automation are property of their respective companies.
Handle On - Open or Close Enclosure Handle On with Defeater Plug
Handle Off - Open or Close Enclosure Lock handle Off with Enclosure Door Interlock
1
2
1
2
1
2
mm
(in.)
1
2
3.5 mm Max.
.140 in. Max.
Publication 140U-IN049A-EN-P - January 2013
A
104.8
(4-1/8)
139.7
(5-1/2)
27
(1-1/16)
61.9
(2-7/16)
34.9
(1-3/8)
34.9
(1-3/8)
34.83
(1-3/8)
34.83
(1-3/8)
7.95
(5/16)
7.95
(5/16)
B C D E
3 Pole
Breaker
4 Pole
177.8
(7)
Mounting Plate
Load Side
Line Side
4 Pole Outline 3 Pole Outline
139.7
(5-1/2)
139.4
(5 - 1/2)
84.9
(3 - 11/32)
170.6
(6 - 23/32)
679.4
(26 - 3/4)
A
B C
E
D
A
51
(2-1/64)
114
(4-31/64)
Max. (12” Operating Shaft)
450.8
(17 - 3/4)
Max. (21” Operating Shaft)
196.8
(7 - 3/4)
Min.
Reset
B C
Mounting Plate
For 3 Pole Breaker Mounting:
Drill and tap four M4 x .7 holes into
mounting plate.
For 4 Pole Breaker Mounting:
Drill and tap six M4 x .7 holes into
mounting plate.
