Rockwell Automation 523 NEMA Combination Starter Accessories For Field Installation User Manual
Page 4
Section 6: Pilot Device Accessories (Continued)
Replacement Bulbs for all Pilot Lights
Lens Color
Clear
Amber
Green
Red
Blue
White
Incandescent
800T-N169
800T-N169
800T-N169
800T-N169
800T-N169
800T-N169
Incandescent
800T-N65
800T-N65
800T-N65
800T-N65
800T-N65
800T-N65
LED
n/a
800T-N320A
800T-N320G
800T-N320R
800T-N320B
800T-N320W
LED
800T-318W
800T-N318A
800T-N318G
800T-N318R
800T-N318B
800T-N318W
Section 7: Enclosure Accessories
Enclosure Type
Nema Starter Size
START-STOP
START-STOP
FOR-REV-STOP
FOR-REV-STOP
HIGH-LOW-STOP
HIGH-LOW-STOP
Push Button Kits
0-7
0-6
0-7
0-6
0-7
0-6
1, 3R/4/12
4, 4X
1, 3R/4/12
4, 4X
1, 3R/4/12
4/4X
OFF-ON
OFF-ON
HAND-OFF-AUTO
HAND-OFF-AUTO
FOR-OFF-REV
FOR-OFF-REV
TEST-OFF-AUTO (Spring Return from TEST)
TEST-OFF-AUTO (Spring Return from TEST)
Bonding Bracket for Pilot Devices
Selector Switch Kits
0-7
0-6
0-7
0-6
0-7
0-6
0-7
0-6
0-7
1, 3R/4/12
4/4X
1, 3R/4/12
4/4X
1, 3R/4/12
4/4X
1, 3R/4/12
4/4X
1, 3R, 3R/4/12
599-SS09OJ
599-SS09OS
599-SS09HJ
599-SS09HS
599-SS09RJ
599-SS09RS
599-SS09TJ
599-SS09TS
800T-N300
+ These handles require 1494V-RB1 or -RB2 connecting rods
1/2 in., 12.7 mm
3/4 in., 19mm
1 in. 25.4 mm
1-1/4 in., 31.75 mm,
1-1/2 in., 38.1 mm,
2 in., 50.8 mm
2-1/2 in., 63.5 mm
3 in., 76.2 mm
0-1
0-1
0-1
2
3
4
4
5
4/4X
4/4X
4/4X
4/4X
4/4X
4/4X
4/4X
4/4X
1490-N1
1490-N9
1490-N10
1490-N11
1490-N5
1490-N6
1490-N7
1490-N8
Non Metallic Conduit Connectors (Grounding Adapters Required)
1/2 in., 12.7 mm, #14…#10 Wire Range (AWG)
3/4 in., 19mm, #14…#8 Wire Range (AWG)
1 in. 24.5 mm, #14…#8 Wire Range (AWG)
1-1/4 in., 31.75 mm, #14…#4 Wire Range (AWG)
1-1/2 in., 38.1 mm, #8…#1/0 Wire Range (AWG)
2 in., 50.8 mm, #8…#1/0 Wire Range (AWG)
2-1/2 in., 63.5 mm, #6…#2/0 Wire Range (AWG)
3 i n . , 7 6 . 2 m m , # 6 … # 4 / 0 W i r e R a n g e ( A W G )
0-1
0-1
0-1
2
3
4
4
5
4/4X
4/4X
4/4X
4/4X
4/4X
4/4X
4/4X
4/4X
1490-N19
1490-N20
1490-N21
1490-N22
1490-N23
1490-N24
1490-N25
1490-N26
Grounding Adapters
Painted Metal
5 1/2 in. handle base
7 1/2 in. handle base
7 1/2 in. handle base for 600A Disconnect Switch +
7 1/2 in. handle base for 800A / 1200A Circuit Breaker
0-5
5
6
6,7
1, 3R/4/12, 3R
1, 3R/4/12, 3R
1, 3R/4/12, 3R
1, 3R/4/12, 3R
1494F-M1 or 1494U-HM1
1494F-M2
1494V-H2
1494F-M3
Stainless Steel
5 1/2 in. handle base
7 1/2 in. handle base
7 1/2 in. handle base for 600A Disconnect Switch +
0-5
5
6
4/4X
4/4X
4/4X
1494F-S1 or 1494U-HS1
1494F-S2
1494V-S2
Molded Handle
5 1/2 in. handle base
0-5
1, 3R, 4/4X
1494F-P1 or 1494U-HP1
External Reset Kit
0-5
0-5
1, 3R, 3R/4/12
4/4X
1493-N21
1493-N22
Wall Mounting Feet
0-4
1, 3R, 3R/4/12
598-N2
Pad Mounting Feet
3-4
5-7
3R
3R
598-N4
598-N5
30.5 mm Hole Plug for Pilot Devices
19.5 mm Hole Plug for Resets and Door Safety Hardware
0-7
All
0-5
All
800T-N1
598-N1
Handle Kits with Universal Link for Switch and Breaker
Hole Plugs
Service Entrance Grounding Kit
0-2
3-5
All
All
599-GR1
599-GR2
27 in. (h) x 10 in. (w) x 8.2 in. (d)
30 in. (h) x 20 in. (w) x 9.7 in. (d)
50 in. (h) in. x 22 in. (w) x 11.1 in. (d)
56 in. (h) x 30 in. (w) x 14 in. (d)
60 in. (h) in. x 38 in. (w) x 16 in. (d)
84 in. (h) x 40 in. (w) x 18 in. (d)
0-2
0-4
3-4
5
5-6
6-7
3R/4/12
3R/4/12
3R/4/12
3R/4/12
1, 3R, 3R/4/12
1, 3R, 3R/4/12
1494F-V1
1494F-V2
1494F-V3
1494F-V4
1494F-V5
1494F-V6
Door Safety Hardware Kits
Enclosure Size
Section 8: System Accessories
3-Phase, 240VAC - Time Mark Model 258B
3-Phase, 480VAC - Time Mark Model A258B
Power Monitor Kit (NOTE: Power Monitor Kit Includes the Time Mark Power Monitor, Fuse Blocks and socket)
Panel Mount (6 Point)
Note: Up to 2 (6 point) panels may be added to Combination Starters
Terminal Block
0-7
0-7
0-7
All
All
All
599-PM1
599-PM2
1492-HC6
.1 to 10 Second Timing Range
1.0 to 180 Second Timing Range
.1 to 10 Second Timing Range
1.0 to 180 Second Timing Range
Timing Relays (120 VAC, On Delay - 8 Pin Socket Required - see below)
Timing Relays (120 VAC, Off Delay - 11 Pin Socket Required - see below)
0-7
0-7
All
All
700HT12AA1
700HT12BA1
0-7
0-7
All
All
700HT22AA1
700HT22BA1
2 Form C 120 V
Control Relays (2 Pole - 8 Pin Socket Required - see below)
0-7
All
700-HA32A1
3 Form C 120 V
Control Relays (3 Pole - 11 Pin Socket Required - see below)
0-7
All
700-HA33A1
8 Pin Socket (10 per box)
11 Pin Socket (10 per box)
Relay Sockets
0-7
0-7
All
All
700-HN125
700-HN126
Catalog Number
599-PB09SJ
599-PB09SS
599-PB09RJ
599-PB09RS
599-PB09WJ
599-PB09WS
42052-018-01
DIR 42052-018 (Version 06)
Printed in U.S.A.
