837E Solid-State Temperature Sensors User Manual
Operation
Pub #75054-004-08, March 2013 11
Navigating through the programming menu
Refer to the menu structure in Figure 6 on the following page.
The section labelled A refers to Function groups
The section labelled B refers to the individual Functions within each Function group
The section labelled C identifies the possible values for each function
? To enter the operating menu:
• Press and hold the E key for longer than 3 sec.
? Once in programming mode (BASE will be displayed), toggle between the Function
groups with the + and
 keys
? To enter the Function group, press the E key
? To toggle between functions, repeatedly press the E key (Note that repeatedly pressing
the E key will return you to the Function group.
• Then press the E key to return to the “Function” option
? Once on the desired function, use the + or
 key to change the function value
? Press E to accept the function value
? To save changes, press and hold the E key for longer than 3 sec.
• Once in SAVE, choose YES or NO with the + or
key
• Confirm with the E key (sensor will go through a start-up routine before entering
operating mode)
• Warning code 210 (W210) will appear on the display to indicate a change in
configuration (see “Error and warning codes” section).
Changes take effect only when you choose YES when asked
to save the data.
ATTENTION
