Rockwell Automation 20-750-DB1-D1A PowerFlex 750-Series Internal DB Resistor - Manual (Page 4)

*PN-183678*
PN-183678
www.rockwellautomation.com
Americas: Rockwell Automation, 1201 South Second Street, Milwaukee, WI 53204-2496 USA, Tel: (1) 414.382.2000, Fax: (1) 414.382.4444
Europe/Middle East/Africa: Rockwell Automation, Pegasus Park, De Kleetlaan 12a, 1831 Diegem, Belgium, Tel: (32) 2 663 0600, Fax: (32) 2 663 0640
Asia Pacific: Rockwell Automation, Level 14, Core F, Cyberport 3, 100 Cyberport Road, Hong Kong, Tel: (852) 2887 4788, Fax: (852) 2508 1846
Power, Control and Information Solutions Headquarters
Publication 750-IN003C-MU-P – January 2013
Supersedes 750-IN003B-MU-P – November 2011 Copyright © 2013 Rockwell Automation, Inc. All rights reserved. Printed in USA.
U.S. Allen-Bradley Drives Technical Support - Tel: (1) 262.512.8176, Fax: (1) 262.512.2222, E-mail: [email protected],
Online: www.ab.com/support/abdrives
Frame 2
T15
1.36 N•m (12.0 lb•in)
5
BR1 BR2
0.5 N•m (4.4 lb•in)
#1
6
T15
1.36 N•m (12.0 lb•in)
7
