Table 12 Sensor Media
➊
➊ See the On-Machine Connectivity catalog for complete cable selection information.
➋ Replace symbol with desired length in meters (Example: 889D-F4ACDM-1 for a 1 m cable). Standard cable lengths: 1 m, 2 m, 5 m, and 10 m.
Table 13 Sealing Caps
➌
➌ To achieve IP67 rating, sealing caps must be installed on all unused I/O connections.
Table 14 ArmorBlock Guard I/O Recommended Compatible Cables and Connectors
➊ Replace symbol with 1 (1 m), 2 (2 m), 5 (5 m), or 10 (10 m) for standard cable length.
Description
ArmorStart I/O
Connection
Pin Count Connector Cat. No.
0
0
Input 5-Pin
Straight Female
Straight Male
889D-F4ACDM-
➋
Straight Female
Right Angle Male
889D-F4AACDE-
➋
0
0
Input 5-pin
Straight Female 879D-F4ACDM-
➋
Right Angle Male 879D-R4ACM-
➋
DC Micro Patchcord
DC Micro V-Cable
Description Used on I/O Connection Catalog Number
Plastic Sealing Cap (M12) Input 1485A-M12
Description Cat. No.
DC Micro (M12) Male Cordset 889D-F4HJ- ➊
DC Micro Style Patchcord 889D-F4HJDM- ➊
M12 Terminal Chamber, Straight Male 871A-TS4-DM
M12 Terminal Chamber, Right Angle Male 871A-TR4-DM
