Mounting Replacement
42JT Mounting Sensor to Surface on the Left
42JT Mounting Sensor to Surface on the Right
Remove
competitive sensor
42JT VisiSight
Left side
mounting bracket
Remove
competitive sensor
42JT VisiSight
Right side
mounting bracket
42JS Mounting Sensor to Surface on the Left
42JS Mounting Sensor to Surface on the Right
Remove
competitive sensor
42JS VisiSight
Left side
mounting bracket
Remove
competitive sensor
42JS VisiSight
Right side
mounting bracket
