4
Sensor Dimensions [mm (in.)]
Accessories
Straight Bracket #60--2656 Right Angle Bracket #60--2657 Swivel/Tilt Bracket #60--2649 Apertures
Transmitted Beam and Retroreflective
Sensing Modes only)
AC/DC DC
10
(0.40)
26.5
(1.04)
20.5
(0.81)
34.5
(1.36)
16.5
(0.65)
M18 x 1,0
thread
27
(1.06)
3.6 (0.145) dia.
clearance for #6--32
screw (2 places)
2 m (6.56 ft)
cable
49.7
(1.96)
69
(2.72)
19
(0.75)
4
(0.16)
9.6
(0.38)
32.7
(1.29)
18 mm mounting nut
Sensitivity Adjustment
(diffuse and glass
fiber optic only)
Indicators
46.7
(1.84)
27
(1.06)
16.5
(0.65)
10
(0.40)
20.5
(0.81)
34.5
(1.36)
10
(0.40)
M18x1.0 thread
27.5
(1.08) 9.6
(0.38) 4
(0.16)
19
(0.75) 3.6 (0.145) dia.
clearance for #6--32
screw (2 places)
32.7
(1.29)
10 Adjustment in
each direction
50.08
(2.0)
7.95
(0.31)
28.6
(1.125)
57.15
(2.25)
1 mm Qty. 20 #60--2660
2 mm Qty. 20 #60--2661
4 mm Qty. 20 #60--2662
Aperture Set (4 each) #60--2659
Note : 18 mm nut must be installed
prior to installing aperture if threads
on optics snout are to be used.
Accessories—Description Catalog Number
Mounting Kit 60- 2716
Clamp Style Bracket 871A- BP18
Flush Mount Adaptor 60- 2590
Field Mount Terminal Chamber—4-pin DC micro 871A- TS4- DM
Field Mount Terminal Chamber—3-pin AC micro 871A- TS3- RM
Cordset—2 m (6.5 ft), 4-pin DC micro 889D- F4AC- 2
Cordset—2 m (6.5 ft), 4-pin AC micro 889D- F4AEA- 2
Reflector—1.25 inch diameter 92- 47
Reflector—3 inch diameter 92- 39
Fiber optic cable, glass, bifurcated, 5/16 in. threaded 43GR- TBB25SL
Fiber optic cable, glass, individual, 5/16 in. threaded 43FT- TBB25SL
Notes
1. Damage may occur to sensor housing if torque above 20 in-lb is applied to the 18 mm lockout.
2. Fiber optic sensors come with two 18 mm locknuts (75012--025--01). All other RightSight sensors come with
one thick 18 mm locknut (75012--097--01).
3. Optional mounting kit (60--2716) comes with two 75012--025--01, one 75012--097--01 locknut, internal tooth
star washer, and screws/nuts for through-hole mounting.
PHOTOSWITCH r is a registered trademark of Rockwell Automation.
Visit our web site at www.ab.com.
Publication PA--9705(J)
July 2003
